About this generator
The text keychain cut from sheet material instead of printed. Every layer is one sheet thick: a base with the tab and ring hole, an optional outline layer and the name. Stack three cut layers in contrasting materials, or engrave the name into the top layer and cut fewer pieces.
What you can change
- Layers - 3 cut (base, outline, name), 2 with the name engraved on the outline, 2 (base and name), or 1 with the name engraved
- Material - 3 to 6 mm
- Text and font - 30 bold fonts and a scale
- Outlines - the base outline from 1.5 mm, the middle outline from 1 mm
- Tab - size, ring hole and position; the hole always leaves 1.5 mm of wood
Cutting and assembly
You get a ZIP with a DXF and an SVG. Engraving is orange, inner cuts are blue, outlines red and part names green, so LightBurn imports them as separate layers in the right order. Sizes are net - set the kerf in your laser software, not here. Glue the layers in order, the letters last; each letter sits where it was cut on the sheet, so lay the name piece over its outline before you pick the letters off. Thin script fonts make thin letter pieces - for those, engrave the name.
Frequently asked questions
Which file formats can I download?
Laser-Cut Text Keychain - layered plywood or engraved exports as DXF, SVG. STL works in any slicer (Bambu Studio, OrcaSlicer, PrusaSlicer, Cura). 3MF preserves multi-color metadata for AMS / MMU-equipped printers.
Is this generator free to use?
Yes, with a free account: 5 files a day and 30 a month, counted together across all free generators. No credit card needed. Past that, a file costs 3 credits.
Can I customize the dimensions and details?
Yes — all parameters (size, walls, hole grid, chamfer, color) are live-adjustable in the browser. The 3D preview updates instantly as you tweak sliders.
Do I need an account?
An account lets you save drafts, sync settings across devices, and use the free daily quota. Browse and preview without one — login only required for download.
